Cane Creek DB Coil IL G2 - 210x50mm
BAD2611
The Cane Creek Coil IL Gen 2 is a high-performance rear shock engineered for aggressive trail and enduro riders seeking unmatched small-bump sensitivity, consistent damping, and robust build quality. This second-generation Coil IL shock features Cane Creek’s class-leading DB Twin Tube technology, offering a wide range of four-way damping adjustments to fine-tune your ride to perfection.
The Coil IL Gen 2 now incorporates a thicker inner damper tube for enhanced strength and a 17mm reduction in overall width on the valve body, increasing fitment possibilities for modern frames with tight clearances. The preload collar also features added detents, allowing more precise preload tuning for optimal sag and initial support.
Hand-assembled and individually dyno-tested at Cane Creek’s facility in Western North Carolina, the Coil IL Gen 2 delivers the performance and quality that riders have come to expect from Cane Creek.
Features:
-
Twin Tube Technology: Provides consistent damping performance and exceptional small-bump sensitivity by continuously circulating oil through the damping valves.
-
Four-Way Independent Adjustment: External adjusters for high- and low-speed compression and rebound provide extensive tuning capabilities.
-
Improved Fitment: 17mm narrower valve body improves clearance on frames with limited space.
-
Enhanced Durability: Thicker inner damper tube increases strength for aggressive riding.
-
Precise Preload Tuning: Detented preload collar enables more accurate spring preload adjustment.
-
Hand-Built Quality: Assembled and individually dyno-tested in Cane Creek’s North Carolina facility.
Specifications:
-
Weight: Approximately 280g (210mm size, damper only, varies by size)
-
Damping: Twin-tube independent compression and rebound circuits
-
Adjustments: High-speed compression & rebound, low-speed compression & rebound, Climb Switch, spring preload
-
Mounting Options: Standard or Trunnion
-
Sizes Available: 165x37.5mm, 165x40mm, 165x42.5mm, 165x45mm, 185x47.5mm, 185x50mm, 185x52.5mm, 185x55mm, 210x50mm, 210x52.5mm, 210x55mm
Compatibility:
The Coil IL Gen 2 is compatible with a wide range of modern mountain bike frames. For specific fitment, refer to your frame manufacturer's specifications regarding shock dimensions and mounting standards. Note: This shock is not compatible with Specialized Levo or Stumpy frames, and is not recommended for use on frames featuring Clevis-style or horse-shoe shaped linkages (such as the Specialized Stumpy/Levo).
Installation Notes:
Installation requires standard suspension tools and knowledge. Professional setup is recommended to ensure optimal performance and safety.
